ProfiLED
Plug & Play LED System
for Maximum Impact. for Unlimited Creativity. for Endless Possibilities.
Complete lighting system with 10 LED bars. Controller and power included—everything in one package. Modular, versatile, and built to light up any stage, set, or installation.
ProfiLED
Visual Performance
Deliver smooth, vibrant colors and even play full video content across multiple bars. With the ability to connect up to 10 units in series, the system scales seamlessly for both small and large projects. Every setup shines with consistent, professional-quality visuals.
Vibrant RGB Output
3 color channels with rich red (620 nm), green (520 nm), and blue (465 nm)
High Brightness
400 lm per meter with CRI >80
Smooth Video Playback
60 pixels per meter, 8-bit grayscale
Wide Coverage
150° beam angle for uniform light
Snap & Lock
Quick push-lock connections with 4-pin M12
Easy Mounting
Secure with clamps or rails in any position
Modular Design
Connect up to 10 bars in series.
Lightweight Build
Only 1 kg per meter, easy to handle
ProfiLED
Quick & Flexible Installation
Setting up takes just seconds with fast snap connections and versatile mounting options. Whether standing, lying flat, or shaped into custom forms, the bars adapt to any stage or installation design. Their modular build makes creative layouts simple and efficient.
ProfiLED
Reliable & Professional
The waterproof design ensures durability indoors and outdoors, even in challenging conditions. Built-in data caching keeps the system running smoothly, so one faulty LED won’t stop the show. Developed for professionals, the bars provide dependable performance every time.
Durable Housing
Black anodized aluminum profile
Light diffuser cover
Opal polycarbonate that evenly disperses light, creating a smooth glow and eliminating visible LED hotspots.
4-Pin M12 Connector (Female)
Quick-lock design, ideal for outdoor or harsh-environment applications.
4-Pin M12 Connector (Male)
Quick-lock design, ideal for outdoor or harsh-environment applications.
Sliding mounting bracket
Adjustable base with 4 versatile holes for secure and flexible mounting options.
Locking Pin
Quick, spring-loaded pin that securely holds brackets in place.
Waterproof Build
IP68 rating, safe for outdoor use.
All-Weather Ready
Operates from +65°C to -20°C.
Failsafe Data Caching
Keeps visuals running even if one LED fails.
ProfiLED
Control & Power
Each system comes with a dedicated LED controller featuring a built-in power supply. Multiple control options — stand-alone (SD card), LSS3 software, DMX, or ArtNet — make it easy to integrate into any setup. Onboard buttons add quick access for simple animation changes without extra hardware.
POWERED LED CONTROLLER
Controller for your 10-bar LED system.
Easily manage all 10 bars in large or rental installations. Plug-and-play with integrated power and daisy-chainable connections.
Flexible Control
Works with Art-Net™, DMX, or in standalone mode
Reliable Power
Integrated power supply ensures stable operation
Simple Installation
Daisy-chain power and Ethernet signals for easy setup
LED STRIP STUDIO 3
Ultimate pixel LED control software to control intelligent addressable LEDs without considering their shape, size or placement. Running on Windows™ and compatible with every standard Art-Net controller.
Advanced Mapping Editor
Design complex LED layouts with ease
Realistic Visualization
Preview your projects in real time
Color & Video Effects
Create stunning dynamic visuals
Live HDMI / BlackMagic Grabber
Stream live content directly to LEDs
Timeline Editor
Build and sync shows with music
ProfiLED
LED Pixel Bar System
2,750.00 EUR
All-in-one package: 10 LED bars, controller with power, and LED Strip Studio software—plug, connect, and bring your lighting vision to life instantly
Any questions? Contact us!
FAQ
How many LED bars can be connected to one controller?
Each controller can operate up to 20 LED bar fixtures, with a maximum of 10 LED bars per output.
Can multiple ProfiLED controllers be connected together?
Yes. Multiple controllers can be daisy-chained for larger installations.
Can I use ProfiLED with third-party hardware or software?
Yes. ProfiLED supports Art-Net and DMX, allowing integration with compatible consoles and software.
Are the LED bars viable for outdoor use?
Yes. They are IP68-rated (water and dust resistant) and operate in temperatures from –20°C to 65°C.
What happens if one LED bar fails?
If one LED bar fails, the rest of the system continues to operate due to integrated data backup.
