Pixel Upgrade – SPI Matrix

200.00350.00 excl. VAT

Upgrade pixel level and use more pixels with a single LED controller. If you don’t have SPI Matrix device, please, buy it here.

In order to Upgrade your pixel level count, we need a serial number of the device. You can find it in the Status tab. You can send it to us in a note in Checkout.

The maximum pixel level is 4096 RGB LEDs per each LED controller.

You can do the upgrade in pixel levels / Art-Net universes:
  1. Level – SPI Matrix 1024 RGB pixels (6 Art-Net universes)
  2. Level – SPI Matrix 2048 RGB pixels (12 Art-Net universes)
  3. Level – SPI Matrix 4096 RGB pixels (24 Art-Net universes)



Description

SPI Matrix can be controlled by Art-Net (24 Art-net universes maximal), DMX or can be operated by its stand-alone mode. Maximum of programmable RGB / RGBW LEDs is 4096 RGB / 3072 RGBW LEDs. There are 4 SPI LED outputs. The maximum of RGB LEDs per Output is 1024/768.

Required Input is 5-24V/ 0.3A (PCB only, without the LED strips / LED pixels) and maximal current is 10 A. Power connector and SPI out connector is standard 4 pin terminal with 5mm contact spacing e.g. SH04-5-GYLED.

SPI Matrix supports the most common connectors such as RJ-45, XLR in/out and SPI connectors for your LEDs. You can also find a slot for SD-Card, DIP switch and buttons for control in stand-alone mode. An optimal SD card is Micro SD Card (FAT32, up to 32 GB).

LED Strip Studio software license is not included with SPI Matrix, but you can use it to control third-party art-net hardware and software. In case you like to upgrade SPI Matrix on LED Ethernet Controller contact our support team.

In order to Upgrade your pixel level count, we need a serial number of the device. You can find it in the Status tab. You can send it to us in a note in Checkout. You can find further information and update tutorial on our wiki – How to Pixel upgrade your controller?
