Analog Mr. Dimmer – high frequency PWM

Description

Mr. Dimmer allows you to control 4 (5) individual analog RGBW (RGB) LED strips (4 (5) outputs * 4 (3) channels) with 16-bit color channel precision. RGB/RGBW OUT connector is standard 5 pin terminal with 5 mm contact spacing e.g. SH04-5-GY.

Mr. Dimmer can be controlled by DMX and built-in Wireless DMX (on request with Radio Lumen module).  The maximal output current is 13.4A with a default 24V/320W power supply. Max. Current per channel is 5 A. Required Input is 88 ~ 264 VAC/47 ~ 63Hz (370W, without the LED strips). Original Neutrik PowerCON connector 230V/20A for power connectors . Power-Con Daisy-chain is one of the most useful features which is also supported in Mr. Dimmer.

DMX input & output connector is XLR 3-pin connector (optional 5 pin) + RJ-45.

Thanks to built-in 320 W 24V DC power supply Mr. Dimmer, you can use Mr.Dimmer for up to 52 meters of Analog LED Strips, 30 LEDs per meter. Please note that the maximal current per each analog output is 13 A. We are offering several types of a power supply which can be integrated inside of Mr. Dimmer – 320W 24V, 320W 12V, 200W 24V (fanless), 200W 12V (fanless), another optional power supply on request.

Examples of analog LED strip quantity you can control with the default Mr. Dimmer device:

• 52m at density 30 RGB LED/m
• 26m at density 60 RGB LED/m
• 13m at density 120 RGB LED/m
